This Klein ET450 Advanced Circuit Tracer Kit is a top - notch solution for tracing energized or non - energized breakers, fuses, and wires. It comes with a comprehensive set of accessories: a transmitter, a receiver, blade and ground prongs, two alligator clips, 3 - foot and 20 - foot lead adapters, AC plug leads, detailed instructions, ten AA alkaline batteries, and a sturdy hard carrying case with a handle for easy transport and storage. One of its remarkable features is the ability to adjust the receiver's sensitivity effortlessly. This allows you to detect the transmitted signal through drywall, cement block, and even underground. It has versatile applications, like tracing wires, conduits, pipes, or a single wire within a bundle. The receiver has an audible beep and visual indicators to show signal strength, a built - in flashlight for low - light areas, and an NCV function to test wire energization. The transmitter features AC/DC external voltage indicators for 12V, 48V, 120V, 240V, and 480V. With a battery life of up to 24 hours, drop protection of 6 feet, and an IP42 ingress protection rating, this kit is both durable and reliable. Its LCD backlit display on the receiver and CAT III 600V standard make it a professional - grade tool for electrical tracing tasks.
Using the Klein ET450 Advanced Circuit Tracer Kit is easy. First, connect the transmitter to the circuit you want to trace. Then, adjust the receiver's sensitivity level so you can detect the signal. You can use it to trace wires through different materials like drywall and underground. The audible beep and visual indicators on the receiver will tell you the signal strength. When in low - light areas, you can use the flashlight on the receiver. And you can use the NCV function to check if the wires are energized. As for the batteries, the transmitter needs 6 AA alkaline batteries and the receiver needs 4. They can last up to 24 hours. Be careful not to drop the kit from a height greater than 6 feet as it has drop protection up to that level. Keep the kit in a dry place to maintain its IP42 ingress protection. If you need to store the leads, remember they are interchangeable. Also, make sure to follow the included instructions for any specific safety or operating details. The hard carrying case is great for storing and transporting the kit, so always keep the accessories organized inside it.
