The Makita XPP01T1K 18V LXT Cordless 5/16 Metal Hole Puncher Kit offers unparalleled convenience and performance. It comes with a range of essential components: a 18V LXT® 5/16' Metal Hole Puncher (XPP01ZK), a 18V LXT® Lithium - Ion Rapid Optimum Charger (DC18RC), a 18V LXT® Lithium - Ion 5.0Ah Battery (BL1850B), and various punches, dies, tools, and accessories like wrenches, oil, a nut bar, and a side handle. This kit is part of Makita’s extensive 18V LXT® System, the world's largest cordless tool system powered by 18V lithium - ion slide - style batteries. The 18V LXT® Lithium - Ion battery enables complete cordless mobility, eliminating the hassle of cords. With a 5.0Ah 18V LXT® Battery, it can punch up to 180 holes of 25/32' diameter in 15/64' thick steel. The punch stop mechanism automatically retracts the die after a punch, allowing for quick continued operation. The 360° rotating grip handle provides optimal positioning in different spaces, and the adjustable depth guide lets you adjust the punch location up to 1 - 37/64' (40 mm) from the workpiece edge. It can handle a max metal plate thickness of 5/16' in general steel and 15/64' in stainless steel. Hole punching is fast, taking under 5 seconds. The ergonomic pistol grip with a rubberized soft grip offers enhanced comfort. The built - in L.E.D. light illuminates the work area, and the return lever allows mid - operation punch retraction. All metal gears and housing ensure maximum job site durability. The battery BL1850B has an integrated L.E.D. charge level indicator and reaches a full charge in 45 minutes or less. It's equipped with Star Protection Computer Controls™ to safeguard against overloading, over - discharging, and over - heating. The Rapid Optimum Charger optimizes battery life by controlling current, voltage, and temperature during charging. Ideal for fabrication, HVAC, plumbing, electrical, and mechanical applications.
Using the Makita XPP01T1K is easy. First, charge the 18V LXT® Lithium - Ion 5.0Ah Battery using the Rapid Optimum Charger. It'll take about 45 minutes or less to fully charge. Once charged, insert the battery into the hole puncher. Adjust the depth guide according to your needs, up to 1 - 37/64' from the edge of the workpiece. Position the puncher where you want to make a hole, using the rotating grip handle to get the best angle. Then, start the punching process. The punch stop mechanism will automatically retract the die when the punch is done, so you can quickly move on to the next hole. When you're in the middle of punching and need to stop, use the return lever to retract the punch. As for maintenance, keep the tool clean and dry. After using it, wipe off any dirt or debris. Check the all - metal gears and housing regularly for any signs of wear. Also, make sure to use the provided 35 ml oil to keep the moving parts lubricated. When storing the tool, remove the battery and keep it in a cool, dry place. And always remember, this tool is equipped with Star Protection Computer Controls™, so don't try to overload it or use it in extreme conditions. This will protect the tool and the battery from over - discharging and over - heating.
